IP Rating IP66
.Improved structure size for easy fitting
Downloads
| Model No | Colour | Size (mm) Set | Size (mm) Plate | Size (mm) H-Cover | Size (mm) H-Base | IP Rating |
|---|---|---|---|---|---|---|
| ADB077-055 | Grey | 77.5*77.5*55 | 77*77 | 4.8 | 47.7 | IP66 |
| ADB110-005 | Grey | 109*109*73 | 100*100 | 32 | 42 | IP66 |
| ADB151-008 | Grey | 159*119*80 | 153*112 | 23 | 57 | IP66 |
| ADB191-009 | Grey | 201*155*140 | 195*148 | 70 | 70 | IP66 |
| ADB191T-009 | Grey, Clear Lid | 201*155*140 | 195*148 | 70 | 70 | IP66 |
| ADB225-010 | Grey | 230*180*90.5 | 224*174 | 18 | 73 | IP66 |
